Features:

• Conforms to IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3x standards.
• 4*10/100/1000 Base-T Ethernet ports (Data/Power), 2*10/100/1000 Base-T Ethernet ports (Data).
• 4K MAC address and MAC address auto learning.
• IEEE 802.3x full-duplex flow control and half-duplex backpressure flow control.
• 12 Gbps non-blocking wire-speed forwarding backplane bandwidth.
• The maximum output power of a single PoE port: 30 W, the maximum output power of PoE of the whole machine: 50 W.
• Support multiple installation methods such as desktop and wall-mounted, plug and play.
• Desktop and wall-mounted design, plug and play

Main Features

• Standard & VLAN

Supports two modes of standard sharing and VLAN isolation, flexible and changeable, can adapt to complex networking environments, and save networking costs.

• 4KV Lightning Protection

Provide 4KV high-level lightning protection. PoE supports short-circuit and overload protection; power supply supports over-temperature protection and over-voltage protection.

• Dual Port Gigabit Uplink

Provide 2*10/100M/1000M uplink ports, which can be connected to NVR and router at the same time, local monitoring and cloud monitoring at the same time.

• QoS Priority

Device 1-2 ports support QoS priority, when network congestion occurs, priority can be given to ensure stable and smooth transmission of important monitoring images.
